CAMERA
- 32x optical zoom
- convertible in the day and night (ICR)
OPTICAL SYSTEM
- Light source: 1500W five-color LED module (RGBLA)
- Average Life expectancy: 20000h
- CRI: Ra＞95,R9＞90,TLCI＞90
- Beam angle: 5°~50°
- Color temperature: 6250K±250K
COLOR SYSTEM
- CTO color temperature linear range 2500K- 8000K
- Virtual color wheel: 1 color wheel with 6 color filters + white
GOBO SYSTEM
- 1 rotating gobo wheel, with 6 gobos filters(pluggable) +white
- 1 fixed gobo wheel, with 6 gobos filters +white
- 1 animation wheel
- 1 set of full directional framing system, cutting gobo ±90° rotation
EFFECTS
- Dimmer: 0-100% linear dimmer
- Soft light: 2pcs independent frosts, can be superimposed, linear adjustment
- Strobe: Electric fast strobe frequency, multiple strobe effects (pulse/asynchronous/synchronous/ slow- medium-fast at random)
- Prism: 1pc 4-facet rotating prism + 1 pc rotating 4-facet gradient prism, can be bidirectional rotation
- Fast electric iris, 5-100% linear adjustment
MOVEMENT PARAMETER
- Pan 540°,16 bit control
- Tilt 270°, 16 bit control
- Magnetic encoder positioning system is used for pan & tilt
CONTROL AND PROGRAMMING
- Channel control: 39(Standard)/ 48(16Bit)/ 55(Extend)
- Protocol: DMX512/RDM, sACN, Art-net(optional)
- Menu display: 3.5 inch black & white LCD display screen, Chinese and English language can be switched freely; font can be reversed 180° display; non-contact roller operation mode, Quick return key
ELECTRONIC CONTROL TECHNOLOGY
- Built-in self-rechargeable battery, edit menu when there is no power
- When the light is turned off, the power is automatically reduced, saving energy and environmental protection
- Intelligent control of the fans
- Heat dissipation system: Intelligent heat dissipation: The advanced and scientific thermal system design keeps the internal systems of the device within a reasonable working temperature range, which can extend the service life of the device and improve the reliability of the device
- Electronic sensor detection
- DMX channel level monitoring
- The XY axis is driven by a three-phase motor, with smooth low-speed scanning and low noise
- Query device information via display screen (power-on time, bulb usage time, fault information, etc.)
- Electronic zoom function
- RDM data bidirectional transmission function
- The software upgrade device can be connected to the DMX port of the device to upgrade the software
- Input signal isolation protection function
- FINE ART CLOUD system
POWER SUPPLY
- Input voltage: AC200-240V(AC100-240V optional), 50/60Hz
- Input power: 1200W
- PF≥0.98
- Signal input/output: 5-pin/3-pin XLR socket input/output
WORKING ENVIRONMENT
- Working temperature: -10°C ~40°C
DIMENSION AND WEIGHT
- Fixture Dimension: 671 x 549 x 829mm
- Package Dimension: 701 x 579 x 844mm
- Net Weight: 47 kg (fixture)
- Gross Weight: 84 kg (flight case)
PACKAGE
- 1 set / flight case
- 1 set /carton
INSTALL
- Horizontal or vertical installation, can be side-mounted
- 2 pcs folding clamps for φ40~60mm truss
- Safety rope connection hole
IP RATE
- IP 20
