Source
• Light source type: 12x 40W RGBW multichips
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency zoom optical system, ratio 15,5:1
• Zoom range: 3.8° – 60°
• Fixture total lumen output:
• 8.200 lm (integrating sphere)
• 6.574 lm (goniophotometer)
• Illuminance: 28.200 lx @ 5 m
• RLCT™ Innovative lens coating technology (Patent pending)
Dynamic Effects and Features
• Colour mixing mode RGBW or CMY
• White light: Variable CCT 2.700K – 8.000K
• DataSwatch™ filters: pre-programmed 66 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)
• Motorized exceptionally quiet zoom
• Electronic strobe effect with variable speed up to 20 Hz, pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• Extremely quiet operation suitable for all types of production in Theatre and TV
• 8.200 lm (integrating sphere)
• 6.574 lm (goniophotometer)
Control and programming
• Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 3 editable programs (each up to 40 steps)
• Protocols:
• USITT DMX-512, RDM
• ArtNet, MA Net, MA Net2, sACN – on request
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity – on request
• DMX Protocol modes: 3
• Control channels: 22, 16, 24
• Pan & Tilt resolution: 16 bit
• RGBW / CMY: 8 or 16 bit
• Zoom: 8 or 16 bit
• Dimmer: 8 or 16 bit (internal 18 bit)
Movement
• Pan movement:
• 540° standard
• 450° reduced
• Tilt position correction• Tilt movement: 228°
• Movement control: Standard and Speed
• Controllable speed of Pan & Tilt movement
• Automatic Pan & Tilt position correction
Thermal specification
• Maximum ambient temperature: 45°C (113°F)
• Maximum surface temperature: 80°C (176°F)
• Minimum operating temperature: -5°C (23°F)
• Total heat dissipation: max. 1153 BTU/h (calculated)
• USITT DMX-512, RDM
• ArtNet, MA Net, MA Net2, sACN – on request
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: Max. 450 W
• Power connector in/out: Neutrik powerCON TRUE1 in/out
• DMX and RDM data in/out: Locking 5-pin XLR
• Ethernet port in/out: RJ45, for Embedded Epass™ switch 10/100 Mbps – on request
