Source
• Light source type: 9 modules of 7 x 40W RGBW multichips and 20 x 10W White strobe LEDs
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency zoom optical system, ratio 13:1
• Zoom range: 3.8° – 50°
• Fixture total lumen output:
75.000 lm (integrating sphere)
58.500 lm (goniophotometer)
• Illuminance: 118.000 lx @ 5 m
• RLCT™ Innovative lens coating technology
• M-CEC™ (Multisource Central Extended Combination) system. This compact, quiet design synchronizes chamber and zoom movement, ensuring shadowless output without light loss
• ReMount-S™ design greatly improves light smoothness, in-lens appearance and the efficiency of the optical system
Dynamic Effects and Features
• Colour mixing mode RGBW or CMY
• + – Green correction function
• Individual control of each RGBW pixel
• 9 individually controllable Strobe LED zones
• White light: Variable CCT standard range 2.700K – 8.000K, extended range 1.800K – 10.000K
• DataSwatch™ filters: pre-programmed 66 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4200K (red shift and thermal delay)
• Motorised exceptionally quiet zoom
• High resolution electronic dimming: 0 – 100%
• Electronic strobe effect with variable speed up to 20 Hz, pre-programmed random strobe & pulse effects
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
Control and programming
• Setting & Addressing: ROBE Navigation System 3 (RNS3)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity
• DMX Protocol modes: 5
• Control channels: 21, 21, 124, 286, 384
Movement
• Pan movement: Manual
• Tilt movement: Manual
Electrical specification and connections
• SVOPATT™ Driver
Power supply: Electronic auto-ranging
Input voltage range: 200-240 V, 50/60 Hz
Power consumption: Max. 2400 W
Power connector in: Neutrik powerCON TRUE1
DMX and RDM data in/out: Locking 5-pin XLR connectors
Ethernet port in/out: RJ45, for Embedded Epass™ switch 10/100 Mbps
Power connector out: Amphenol connector
• SVOPATT™
Data in: Locking 4-pin XLR connector
Power connector in: Amphenol connector
