PERFORMANCE
- Frequency Range (-10 dB)
- 75 Hz – 20,000 Hz
- Coverage, Horizontal
- 130° conical
- Calculated Maximum SPL @ 1 m
- 99 dB
- Nominal Impedance
- 8 Ω (transformer bypass)
- Power Handling, long-term continuous
- 25 W
- Power Handling, Peak
- 100 W
- Recommended Signal Processing
- Not required, Bose Professional EQ voicing and SmartBass processing available
- Sensitivity (SPL/1 W at 1 m)
- 84 dB
- Transformer Taps, 100V
- 6, 12, 25 W, bypass
- Transformer Taps, 70V
- 3 W, 6 W, 12 W, 25 W, bypass
- Coverage, Vertical
- 130° conical
TRANSDUCERS
- Crossover
- 1.7 kHz, passive 2-way crossover
- Driver Protection
- Recommended high-pass protection 80 Hz with minimum 24 dB/octave filter
- High-Frequency
- 1 × 0.75 in (20 mm) neodymium dome tweeter, coaxially mounted
- Low-Frequency
- 1 × 3.25 in (83 mm) woofer
