Funktion One Evo 7EL Mid-Bass Arrayable Loudspeaker

Evo 7EL supplements Evo 7E cabinets to provide additional mid bass headroom – especially useful for flown Evo 7E installations.
It shares the same footprint as the Evo 7E, and is attached via the vertical or side M10 mounting points. The joined assembly can be ground stacked or flown using the appropriate hardware. Pairs well with F121 or F124 to form a complete system.

•Identical footprint and hardware to Evo 7E
•Integral handles
•Optional grille and wheel board
•Available in ultra durable black PU coating or classic FunktionOne violet finish

分類: Funktion One, Funktion One

描述

Frequency Response: 70Hz-300Hz

Weight: 30kg (66lbs)

Nominal Dispersion: Array dependant

Connectors: 2 x Neutrik NL8 or NL4

Driver: 15″ (LF)

Crossover: 85Hz – 220Hz

Frequencies Sensitivity (at 1m)*: 103dB at 2.8V

Power (AES): 400W

Nominal Impedance: 8Ω
