Source
• Light source type: 7x 40W RGBW multichips
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
Optical system
• Robe’s proprietary optical design
• High – efficiency zoom optical system, ratio: 15,5:1
• Zoom range: 3,8° – 60°
• Fixture total lumen output:
3.550 lm (integrating sphere)
2.842 lm (goniophotometer)
• Illuminance: 12.200lx @ 5 m
• RLCT™ Innovative lens coating technology
Dynamic Effects and Features
• Colour mixing mode RGBW or CMY
• Variable CTO: 2.700K – 8.000K
• DataSwatch™ filters: pre-programmed 66 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)
• Motorized zoom
• Pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
Control and programming
• Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 3 editable programs (each up to 40 steps)
• Protocols: USITT DMX-512, RDM
• Wireless CRMX™ technology from Lumen Radio – on request
• DMX Protocol modes: 2
• Control channels: 22, 16
• Pan/Tilt resolution: 8 or 16 bit
• RGBW/CMY: 8 or 16 bit
• Zoom: 8 or 16 bit
• Dimmer: 8 or 16 bit (internal 18 bit)
Movement
• Pan movement: 450°
• Tilt movement: 228°
• Movement control: Standard and Speed
• Controllable speed of Pan/Tilt movement
• Automatic Pan/Tilt position correction
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: Max. 220 W
• Power in/out connector: Neutrik powerCON in/out
• DMX and RDM data in/out: Locking 5-pin XLR
