SPECIFICATION
SOURCE
• Lamp: Discharge short arc lamp with integrated reflector
• Approved model: Osram Sirius HRI 140 W RO
• Life time : 6.000 hours
• CRI: 65
• CCT: 8000 K
• Control: Automatic and remote on/off
• Ballast: Electronic
OPTICAL SYSTEM
• Robe’s proprietary optical design
• Beam angle :
• 3° on full open/hole
• 0.7° / 1.2° / 1.8° with beam reducers
• Output lens diameter: 85 mm
• Fixture total lumen output: 4.960 lm
• Light output: 400,000 lx @ 5 m distance
DYNAMIC EFFECTS
• Colour wheel: 13 dichroic filters + white
• Static Gobo wheel: 10 gobos + 3 beam reducers
• DFE™ – Dynamic Flower Effect – creating spectacular beam effects in the air which can change shape, size and speed of rotation (patent pending)
• Beam Shaper: Variable shape, indexable and rotatable
• Frost effect: Separate, variable
• Motorized focus
• Pre-programmed random strobe & pulse effects
• Dimmer: smooth dimming
CONTROL AND PROGRAMMING
• Setting & Addressing: two-row LCD display & 4 control buttons
• Wireless CRMX™ technology from Lumen Radio: On request
• DMX Protocol modes: 3
• Control channels: 22, 17, 27
• Stand-alone operation
• 3-editable programs, each up to 40 steps
• Pan/Tilt resolution: 16 bit
• Colour wheel positioning: 8 or 16 bit
• Static gobo wheel positioning: 8 bit
• Prism indexing & rotation: 8 bit
• Frost: 8 bit
• Focus: 8 or 16 bit
• Dimmer: 8 or 16 bit
MOVEMENT
• Tilt movement: 270°
• Pan movement: 540°
• Controllable speed of Pan/Tilt movement
STATIC GOBOS
• Aluminium wheel with fixed gobos: 10 gobos & 3 beam reducers
