Source
• Light source type: TE™ 310W HP White LED Engine (Patented):
HP – High Performance Engine for maximum light output and optimal colour characteristics
LED Engine output: 18.500 lm
Fixture total lumen output:
15.200 lm (integrating sphere)
12.250 lm (goniophotometer)
Colour temperature output: 6.700 K
CRI: 70, remotely selectable filter for CRI 90
Illuminance: 23.485 lx @ 5 m
• Light source type: TE™ 310W HCF White LED Engine (Patented):
HCF – High Colour Fidelity Engine for the best light quality and colour rendition
LED Engine output: 13.000 lm
Fixture total lumen output:
9.800 lm (integrating sphere)
7.800 lm (goniophotometer)
Colour temperature output: 6.000 K
CRI: 96, TLCI: 97, TM-30-18 Rf: 92, TM-30-18 Rg: 99
Illuminance: 15.289 lx @ 5 m
• Light source type: TE™ 310W TGW White LED Engine (Patented):
TGW – Simulates the comforting warmth of tungsten lighting
LED Engine output: 10.500 lm
Fixture total lumen output:
8.400 lm (integrating sphere)
6.700 lm (goniophotometer)
Colour temperature output: 3.200 K
CRI: 96, TLCI: 95, TM-30-18 Rf: 93, TM-30-18 Rg: 103
Illuminance: 13.100 lx @ 5 m
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
• Light source warranty: 4 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency 13-lens zoom optical system, ratio: 6:1
• Zoom range: 8°- 48°
• Output lens diameter: 110 mm
Dynamic Effects and Features
• Cyan: 0 – 100%
• Magenta: 0 – 100%
• Yellow: 0 – 100%
• ChromaTint™ – Patented plus / minus green correction function
• Virtual CTO
• Colour Wheel: 9 dichroic filters + white
• Rotating gobo wheel: 8 rotating, indexable and replaceable breakup and aerial gobos + open, patented slot & lock system
• Static gobo wheel: 9 gobos + open
• Full curtain framing shutters: Patented Plano4 FC™ framing shutters module with 4 individually positionable blades plus rotation of the complete framing system +-60°
• Prism: 8-facet prism rotating in both directions at variable speed
• Iris: Motorized, stepless, pulse effects up to 3 Hz
• MagFrost™ – magnetic paddle fast change system providing exchangeable frost containing as standard a medium 5° for even wash
• Motorized zoom and focus
• Electronic strobe effect with variable speed up to 20 Hz
• Extremely quiet operation suitable for all types of production in Theatre and TV
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols:
USITT DMX-512, RDM
ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity – on request
• DMX Protocol modes: 2
• Control channels: 44, 45
Movement
• Pan movement: 540°
• Tilt movement: 270°
• Controllable speed of Pan & Tilt movement
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
• Automatic Pan & Tilt position correction
Rotating gobos
• Glass gobos: 8 rotating gobos + open
• Outside diameter: 15.9 mm
• Image diameter: 12.5 mm
• Thickness: 1.1 mm
• High temperature borofloat or better glass
• Patented slot & lock system for easy replacement of gobos
Static gobos
• Aluminium wheel with fixed gobos: 9 gobos + open position
Framing shutters system
• Full curtain framing shutters: 4 Blades, each with separate movement and rotation control
• Movement: Smooth with variable speed, ultrafast blade movements for creating mid-air effects
• Rotation: +- 60° of the complete framing system
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: max. 440 W
• Power connector in: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 5-pin XLR
• Ethernet port in: RJ45
• Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps – on request
