Input XLR
Input impedance 5.8kΩ
Bit Depth 16-bit/24-bit
Sampling Rate 48kHz
Frequency Response 20Hz to 20,000Hz
Adjustable Gain Range 0 to +60dB
Power Requirements Powered through USB-C
Phantom Power +48VDC
Digital Noise Floor
(20 Hz to 20 kHz, A-weighted) -117dBFS
LED Indicator
(Tricolor)
Green = Ready
Amber = Error
Red = Mute
Housing All Metal
Net Weight 100 g (3.5 Oz.)
Dimension (H x W x D) 44 x 140 x 158mm
Headphone Output 3.5 mm (1/8 inch) 20 mW @ 32Ω
Cable 1M USB-C to USB-C cable
USB USB 2.0
RAM 64MB RAM (minimum)
Shure MVX2U Gen 2 Digital Audio Interface
A compact and mobile-friendly single-channel XLR-to-USB interface designed for recording or streaming on desktop or mobile devices using any XLR microphone. Onboard digital audio processing, powered via USB-C, ensures consistent sound across devices and in imperfect acoustic environments. Provides up to 60 dB of gain and 48 V phantom power for both dynamic and condenser XLR microphones. MFi certified for iPhone and iPad, and compatible with select Mac, Windows, iOS, and Android devices.
- Shure Digital Audio Processing: Features MOTIV series voice isolation technology such as Auto Level Mode that adjusts gain intelligently, Real-time denoiser for removing unwanted background ambience, and Digital Popper Stopper™ to tame plosives.
- Plug-and-Play: Instantly convert any XLR mic for podcasting or streaming like a pro.
- Offers +60 dB gain and 48V phantom power for both dynamic and condenser mics, even for low-sensitivity mics such as SM7B to run on mobile devices.
- Mobile-Friendly: Seamlessly switch creations between devices; record on phone or tablet.
- Plug-on or inline setups: Flexible in connection to reduce cable clutter with XLR mics.
- Compact Design: Just 100g in weight, USB-C powered. External batteries not required.
