Source
• Light source type: TE™ 650W XP White LED Engine (Patented)
HP – High Performance Engine for maximum light output and optimal colour characteristics
LED Engine output: 55.000 lm
Fixture total lumen output:
– 24.450 lm (integrating sphere)
– 19.528 lm (goniophotometer)
Colour temperature output: 6.700 K
CRI: 70, remotely selectable filters for CRI 80 and CRI 90
Illuminance: 47.800 lx @ 5 m
• Light source type: TE™ 650W HCF White LED Engine (Patented)
HCF – High Colour Fidelity Engine for the best light quality and colour rendition
LED Engine output: 37.500 lm
Fixture total lumen output:
– 16.800 lm (integrating sphere)
– 13.279 lm (goniophotometer)
Colour temperature output: 6.000K
CRI: 96, TLCI: 97, TM-30-18 Rf: 92, TM-30-18 Rg: 99
Illuminance: 32.500 lx @ 5 m
• Light source type: TE™ 650W TGW White LED Engine (Patented):
TGW – Simulates the comforting warmth of tungsten lighting
LED Engine output: 30.250 lm
Fixture total lumen output:
– 16.600 lm (integrating sphere)
– 13.300 lm (goniophotometer)
Colour temperature output: 3.200K
CRI: 97, TLCI: 97, TM-30-18 Rf: 93, TM-30-18 Rg: 102
Illuminance: 27.800 lx @ 5 m
• LED life expectancy: min. 50.000 hours
• Colour temperature: 6.700K
• Typical lumen maintenance: L70/B50 @ 50.000 hours
• Light source warranty: 4 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency zoom optical system, ratio 10:1
• Zoom range: 6° – 60°
• Output lens diameter: 156 mm
Dynamic Effects and Features
• Cyan: 0 – 100%
• Magenta: 0 – 100%
• Yellow: 0 – 100%
• Variable CTO: 3.000K – 6.700K
• ChromaTint™ – Patented plus / minus green correction function
• Colour Wheel 1: 5 fixed dichroic colours + white
• Colour Wheel 2: 5 fixed dichroic colours + white
• 4Door™ – Internal Barndoors with individual control of the four leaves for added beam control of wash light, with +/- 90° module rotation (Patented)
• MagFrost™ – Magnetic paddle fast change system providing exchangeable frosts containing as standard light 5° and medium 10° frost filters
• RotaScrim™ – Internal Scrim module with graduated filter position control for asymmetrical style lighting of drapes and unwanted hotspot removal from scenery. The entire module can be rotated +/- 180°. (Patented)
• Motorized zoom and focus
• Edge colour correction
• Electronic strobe effect with variable speed up to 20 Hz
• Pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Cpulse™ special flicker free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity – on request
• DMX Protocol modes: 4
• Control channels: 34, 30, 35, 31
Movement
• Pan movement: 540°
• Tilt movement: 265°
• Movement control: Standard and Speed
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
• Automatic Pan & Tilt position correction
Internal barndoors
• Patented 4Door™ internal barndoors module:
Blades: 4 blades, each with separate movement control
Rotation: +/- 90° module rotation
Internal Scrim
• Patented 4Door™ internal barndoors module:
Graduated filter position control
Rotation: +/- 180° of the entire module
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption:
Standard mode max. 870 W at 230 V / 50 Hz
High-power mode max. 950 W at 230 V / 50 Hz
• Power connector in: Neutrik powerCON TRUE1
• DMX and RDM data in/out: IP65 Locking 3-pin & 5-pin XLR connectors
• Ethernet port out: IP65 RJ45 – camera video output
• Ethernet port in/out: IP65 RJ45, for Embedded Epass™ switch 10/100 Mbps
• USB connector (series C) for lightmaster purposes
