Source
• Light source type: 18x 40W RGBW LED multichips
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
Optical system
• Robe’s proprietary optical design
• Zoom range: 4°- 45°
• Highly efficient component optics
• Fixture total lumen output:
10.500 lm (integrating sphere)
8.439 lm (goniophotometer)
• RLCT™ Innovative lens coating technology (Patent pending)
Dynamic Effects and Features
• Colour mixing mode RGBW or CMY
• Individual control of each RGBW pixel
• Variable CCT: 2.700K – 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)
• DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and direction
• 2x MCFE™ – Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (Patented)
• Motorized zoom
• 2 independent zoom zones
• Pre-programmed random strobe & pulse effects
• Electronic strobe effect with variable speed up to 20 Hz
• High resolution electronic dimming: 0 – 100%
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• POLAR+™ for power saving and instant operation in extremely cold weather conditions
Control and programming
• Setting & Addressing: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 88 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity
• RAINS™ (Robe Automatic Ingress Neutralization System) manages humidity, temperature and pressure control using an active monitoring system to automatically remove any moisture detected within the fixture and provides constant monitoring to ensure peak performance
• DMX Protocol modes: 6
• Control channels: 34, 56, 97, 115, 110, 128
Movement
• Tilt movement: 191°
• 16 bit movement resolution
• Controllable speed of Tilt movement
• MAPS™ – Motionless absolute positioning system for Tilt (Patented)
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: 600 W at 230 V / 50 Hz
• Power connector in/out: Neutrik powerCON TRUE1 in/out
• DMX and RDM data in/out: Locking 5-pin XLR
• Ethernet port in/out: IP65 RJ45 for Embedded Epass™ switch 10/100 Mbps
