Source
• Light source type: 1x 60W RGBW and 18x 40W RGBW LED multichips
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
Optical system
• Robe’s proprietary optical design
• High – efficiency zoom optical system, ratio 12,5:1
• Zoom range: 4° – 50°
• Fixture total lumen output:
• 13.700 lm (integrating sphere)
• 11.000 lm (goniophotometer)
:• Illuminance: 50.100 lx @ 5 m
• (RLCT™) Innovative lens coating technology (Patent pending)
• EasyClean™ – newly designed and patented lens sandwich system for easy cleaning and time saving maintenance
of the lenses
Dynamic Effects and Features
• Colour mixing mode RGBW or CMY
• Individual control of each RGBW pixel
• Variable CTO: 2.700K – 8.000K
• Virtual Colour Wheel: with 66 preset swatches
• Tungsten lamp effect at whites: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)
• Colour rainbow effect with variable speed
• Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and direction
• MCFE™ – Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (patented)
• Strobe effect: variable speed (max. 20 flashes per second)
• Pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net
• Wireless CRMX™ technology from Lumen Radio – on request
• DMX Protocol modes: 10
• Control channels: 49, 27, 33, 90, 27, 47, 91, 110, 104, 123
• Pan/Tilt resolution: 16 bit
• R,G,B,W colour mixing: 8 or 16 bit (internal 18 bit)
• Zoom: 8 bit
• Dimmer: 8 or 16 bit (internal 18 bit)
Movement
• Pan movement: 540°
• Tilt movement: 220°
• Movement control: Standard and Speed
• Controllable speed of Pan/Tilt movement
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
• Automatic Pan/Tilt position correction
Thermal specification
• Maximum ambient temperature: 45 °C (113 °F)
• Maximum surface temperature: 75 °C (167 °F)
• Minimal operating temperature: – 5°C (23 °F)
• Total heat dissipation: max. 1688 BTU/h (calculated)
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: max. 660 W
• Power in connector: Neutric powerCON TRUE1
• DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
• Ethernet port in/out: RJ45
• Embedded Ethernet switch 10/100 Mbps: 1 x in / 1 x out
• USB connector (series A)
