Source
• Light source type: MSL™ 550 W Multi-Spectral LED engine (Patented)
• LED life expectancy: min. 40.000 hours
• Colour rendition: CRI: 95, CRI R9: 91, TM30-18 Rf: 93, TM30-18 Rg: 103, TLCI: 94
• LED life expectancy: min. 40.000 hours
• Typical lumen maintenance: L70/B50 @ 40.000 hours
• Light source warranty: 3 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High – efficiency zoom optical system, ratio 7:1
• Zoom range: 8° – 60°
• Fixture total lumen output:
10.500 lm (integrating sphere)
8.500 lm (goniophotometer)
• Output lens diameter: 156 mm
Dynamic Effects and Features
• Factory calibrated whites and colours via the new RCC™ (Robe Colour Calibration) system, automatic or on-call self-re-calibration of the LED engine without the use of any external tool (Patent pending)
• Colour mixing: CMY/RGB or RGBAL
• White light: Variable CCT 2.700K – 8.000K
• DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4200K (red shift and thermal delay)
• + – Green correction function
• Adjustable CRI from 80 to 95+
• 4Door™ – Internal Barndoors with individual control of the four leaves for added beam control of wash light, with +/- 90° module rotation. (Patented)
• MagFrost™ – Magnetic paddle fast change system providing exchangeable frosts containing as standard light 5° and medium 10° frost filters
• RotaScrim™ – Internal Scrim module with graduated filter position control for asymmetrical style lighting of drapes and unwanted hotspot removal from scenery. The entire module can be rotated +/- 180°. (Patented)
• Motorized zoom
• Edge colour correction
• Electronic strobe effect with variable speed up to 20 Hz
• Pre-programmed random strobe & pulse effects
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Extremely quiet operation suitable for all types of production in Theatre and TV
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity – on request
• DMX Protocol modes: 3
• Control channels: 35, 24, 39
Movement
• Pan movement: 540°
• Tilt movement: 265°
• Movement control: Standard and Speed
• Controllable speed of Pan & Tilt movement
• Automatic Pan & Tilt position correction
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
• MAPS™ – Motionless absolute positioning system for Pan & Tilt (Patented) – on request
Internal barndoors
• Patented 4Door™ internal barndoors module:
Blades: 4 blades, each with separate movement control
Rotation: +/- 90° module rotation
Internal Scrim
• Patented RotaScrim™ internal Scrim module:
Graduated filter position control
Rotation: +/- 180° of the entire module
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: maximum 750 W at 230 V / 50 Hz (all LEDs On)
• Typical power consumption: 160 – 215 W (one colour = full)
• Power in connector: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
• Ethernet port in: RJ45
• Ethernet port in/out: RJ45 (instead of 3-pin XLR) for Embedded Epass™ switch 10/100 Mbps – on request
• USB connector (series A) for lightmaster purposes
