Source
• Light source type: MSL-TE™ 500W LED engine (Patented)
• Colour temperature: 3.200 K
• Colour rendition: CRI 95, TLCI 91
• LED life expectancy: min. 40.000 hours
• Typical lumen maintenance: L70/B50 @ 40.000 hours
• Light source warranty: 4 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency zoom optical system, ratio 9:1
• Zoom range: 5.5° – 50°
• Fixture total lumen output:
13.600 lm (integrating sphere)
11.100 lm (goniophotometer)
• Output lens diameter: 150 mm
Dynamic Effects and Features
• Factory calibrated whites and colours via the new RCC™ (Robe Colour Calibration) system, automatic or on-call self-re-calibration of the LED engine without the use of any external tool (Patent pending)
• Colour mixing: CMY/RGB or RGBAL
• White light: Variable CCT 2.700K – 8.000K
• DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4200K (red shift and thermal delay)
• + – Green correction function
• Adjustable CRI from 80 to 95+
• Framing shutters: Patented Plano4™ framing shutters module with 4 individually positionable blades plus rotation of the complete frame system + – 60°
• Optional drop-in gobo module: Static, rotating gobo wheel and animation wheel
• Static gobo wheel: 9 static, replaceable breakup gobos + open, all gobos specially selected for theatrical and TV productions, patented slot & lock system
• Rotating gobo wheel: 7 rotating, indexable and replaceable breakup and aerial gobos + open, patented slot & lock system
• Animation wheel: Aluminium animation wheel, used alone or in combination with gobos, rotating in both directions at variable speed
• Iris: Motorized, stepless, pulse effects up to 3 Hz
• Frosts: MagFrost™ – magnetic paddle fast change system providing exchangeable frosts containing as standard a very light 1° for instant softening of the projected gobo or framing shutters, and a medium 5° for even wash, both specifically selected for theatre and TV use
• HSL™ – Hot-Spot Lens for LED profiles: from flat field to 6:1 hot-spot (optional)
• Motorized zoom and focus
• Electronic strobe effect with variable speed up to 20 Hz: pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Extremely quiet operation suitable for all types of production in Theatre and TV
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
• BARS™ – Brake Attribute Retention System (Patented) applied for Pan, Tilt, Focus and Zoom stepper motors
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity – on request
• Wireless CRMX™ technology from Lumen Radio – on request
• DMX Protocol modes: 6
• Control channels: 40, 27, 44, 48, 33, 52
Static gobos
• 9x static glass gobos: (with optional drop-in gobo and animation module)
• Aluminium gobo wheel
• High temperature borofloat or better glass
• slot & lock system for easy replacement of gobo
Rotating gobos
• 7x rotating glass gobos: (with optional drop-in gobo and animation module)
• Outside diameter: 26.8 mm
• Image diameter: 23.5 mm
• Thickness: 1.1 mm
• Max. thickness: 4 mm
• High temperature borofloat or better glass
• Patented slot & lock system for easy replacement of gobos
Effect wheel
• Single animation wheel: (with optional drop-in gobo and animation module)
• Material: Aluminium
• Can be used alone or in combination with rotating gobos
• Rotating in both directions at variable speed
Framing shutters system
• Patented Plano4™ framing shutters module
• Shutters: 4 Blades, each with separate movement and +- 25° rotation control
• Movement: Smooth with variable speed, ultrafast blade movements for creating mid-air effects
• Rotation: +- 60° of the complete framing system
• Pre-programmed: Shape and blade sequences
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: max. 640 W
• Power connector in: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
• Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps – on request
• USB connector (series A) for lightmaster purposes
