Shure MXN-AMP PoE+ Powered Multichannel Amplifier

  • Can power up to 4 MXP loudspeakers in 8 ohm mode, or up to 8 MXP-5/MXP-6 loudspeakers in 70V mode.
  • Rated at 14.5 watts of combined output power.
  • Four Dante inputs and four Dante outputs.
  • Unbalanced stereo analog audio input.
  • Logic input (switches between presets 1 and 2 as defined in web UI).
  • Onboard Shure DSP utilities include EQ, delay, limiter, and signal/tone generator.
  • Presets for all MXP-series loudspeakers ensure optimal audio performance.  Custom presets can be defined in the MXN-AMP control software.



分類: , ,

Shure MXN-AMP Specs

Form Factor/Type
Wall-Mount
Number of Amplifier Channels
4
Load Impedance/Voltage Support
8 Ohms
70 V
Power Rating per Channel
1x 3.25 W at 8 Ohms
1x 11.7 W at 70 V
Performance
Protections
No
Signal Processing
DSP
Yes
Audio Delay
Adjustable Up to 2.5 ms
Dynamics
No
Connectivity
Analog Audio I/O
1x 1/8″ / 3.5 mm TRS Unbalanced Line Input
4x Block 2-Pin Speaker Output
1x Block 2-Pin Speaker Output
Digital Audio I/O
No
Network I/O
1x RJ45 Dante (PoE)
Other I/O
1x Block 3-Pin GPIO Input
USB I/O
No
Phantom Power
No
Wireless
No
Power
Input Power
48 VDC
Power Consumption
25.5 W (Max)
Physical
Display
Single-LED Indicators Only
Operating Conditions
19 to 104°F / -7 to 40°C
Dimensions
8 x 7 x 1.6″ / 202 x 178 x 40 mm
Weight
2.4 lb / 1.1 kg
