Specifications
| GENERAL DIGITAL | |
| Sample Rate | 48 kHz |
| A/D/A Bit Depth | 24-bit |
| System Latency | ~3 ms |
| Equivalent Noise | -143.4 dBV (A-weighted) |
| INPUTS | |
| Inputs | 4x balanced/unbalanced combo jacks, 1/4″ balanced/unbalanced stereo jack, 1/8″ stereo jack |
| XLR Mic Pre | Onyx 80 mic preamps |
| Input Impedances | • 4 kΩ balanced (microphone) • 10 kΩ balanced (instrument) • 5 kΩ unbalanced (instrument) |
| OUTPUTS | |
| Outputs | Balanced/unbalanced 1/4″ main out jacks, 4x stereo headphone jacks |
| Line Output Maximum Level | 14 dBu |
| Headphone Output Power | 30 mW |
| BLUETOOTH • USB • SD | |
| Bluetooth | 5.0 |
| USB | Format: USB 2.0 HS (480Mb/s) |
| SD | • Multitrack (12 chan + main mix) / 24-bit / 48kHz • SD speed class 10 or speed class UHS recommended |
| RECORDING / NETWORKING | |
| Recording Storage | microSDHC, microSDXC, USB-A removable drive (FAT32 – minimum 100MB/s) |
| Data Transfer | Integrated SD 3.0 104 MB/s |
| Network Connectivity | Ethernet 10/100 |
| BATTERY & POWER | |
| Battery included | N |
| Line Input Power | 18V ⎓ 1.5A |
| PHYSICAL PROPERTIES (PRODUCT) | |
| Product weight (g) | 329 (Image 1 alternate: 2.8 kg / 6.1 lb) |
| Product height | 80 mm (Image 2 alternate: 103 mm / 4.1 in) |
| Product length / depth | 140 mm (Image 2 alternate: 381 mm / 15.0 in) |
| Product width | 115 mm (Image 2 alternate: 330 mm / 13.0 in) |
| PHYSICAL PROPERTIES (PACKAGED PRODUCT) | |
| Height | 216 mm / 8.5 in |
| Width | 386 mm / 15.2 in |
| Depth | 399 mm / 15.7 in |
| Weight | 4.9 kg / 10.9 lb |
