Source
• Light source type: TE™ 310W HP White LED Engine (Patented):
HP – High Performance Engine for maximum light output and optimal colour characteristics
LED Engine output: 18.500 lm
Fixture total lumen output:
10.850 lm (integrating sphere)
8.670 lm (goniophotometer)
Colour temperature output: 6.700 K
CRI: 70, remotely selectable filter for CRI 90
Illuminance: 20.500 lx @ 5 m
• Light source type: TE™ 310W HCF White LED Engine (Patented):
HCF – High Colour Fidelity Engine for the best light quality and colour rendition
LED Engine output: 13.000 lm
Fixture total lumen output:
7.365 lm (integrating sphere)
5.892 lm (goniophotometer)
Colour temperature output: 6.000K
CRI: 96, TLCI: 97, TM-30-18 Rf: 92, TM-30-18 Rg: 99
Illuminance: 8.395 lx @ 5 m
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
• Light source warranty: 4 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency 13-lens zoom optical system, ratio: 8.3:1
• Zoom range: 6 – 50°
• Output lens diameter: 150 mm
Dynamic Effects and Features
• Cyan: 0 – 100%
• Magenta: 0 – 100%
• Yellow: 0 – 100%
• Variable CTO: 3.000K – 6.700K
• ChromaTint™ – Patented plus / minus green correction function
• Colour Wheel: 9 dichroic filters + white
• 4Door™ – Internal Barndoors with individual control of the four leaves for added beam control of wash light, with +/- 90° module rotation. (Patented)
• MagFrost™ – Magnetic paddle fast change system providing exchangeable frosts containing as standard 5°/10° frost filter
• RotaScrim™ – Internal Scrim module with graduated filter position control for asymmetrical style lighting of drapes and unwanted hotspot removal from scenery. The entire module can be rotated +/- 180°. (Patented)
• Electronic strobe effect with variable speed up to 20 Hz
• Extremely quiet operation suitable for all types of production in Theatre and TV
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation
memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in
analyser for easy fault finding
• Protocols:
USITT DMX-512, RDM
ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to
automatically maintain network connectivity – on request
• DMX Protocol modes: 1
• Control channels: 33
Movement
• Pan movement: 540°
• Tilt movement: 270°
• Controllable speed of Pan & Tilt movement
• EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
• Automatic Pan & Tilt position correction
Internal barndoors
• Patented 4Door™ internal barndoors module
• Blades: 4 blades, each with separate movement control
• Rotation: +/- 90° module rotation
Internal Scrim
• Patented RotaScrim™ internal Scrim module
• Graduated filter position control
• Rotation: +/- 180° of the entire module
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: max. 440 W
• Power connector in: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 5-pin XLR
• Ethernet port in: RJ45
• Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps – on request
