Source
• Light source type: MSL™ 1400 W Multi-Spectral LED engine (Patented)
• LED life expectancy: min. 40.000 hours
• Colour rendition: <br>CRI: 95, CRI R9: 91, TM30-18 Rf: 93, TM30-18 Rg: 103, TLCI: 94
• Typical lumen maintenance: L70/B50 @ 40.000 hours
• Light source warranty: 3 years or 20.000 hours
Optical system
• Robe’s proprietary optical design
• High-efficiency zoom optical system, ratio 11:1
• Zoom range: 6° – 66°
• Fixture total lumen output:
32.300 lm (integrating sphere)
25.000 lm (goniophotometer)
• Output lens diameter: 250 mm
Dynamic Effects and Features
• Factory calibrated whites and colours via the new RCC™ (Robe Colour Calibration) system, automatic or on-call self-re-calibration of the LED engine without the use of any external tool (Patent pending)
• Colour mixing: CMY/RGB or RGBAL
• White light: Variable CCT standard range 2.700K – 8.000K, extended range 1.800K – 10.000K
• DataSwatch™ filters: pre-programmed 66 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4200K (red shift and thermal delay)
• + – Green correction function
• Adjustable CRI from 80 to 95+
• 4Door™ – Internal Barndoors with individual control of the four leaves for added beam control of wash light, with +/- 90° module rotation. (Patented)
• ProFrost™ progressive frost system smoothly softens, melts and dissolves projections from 0° to 15°
• RotaScrim™ – Internal Scrim module with graduated filter position control for asymmetrical style lighting of drapes and unwanted hotspot removal from scenery. The entire module can be rotated +/- 180°. (Patented)
• Motorised zoom
• ECC™ – Edge Colour Correction
• Electronic strobe effect with variable speed up to 20 Hz
• Pre-programmed random strobe & pulse effects
• L3™ – (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Extremely quiet operation suitable for all types of production in Theatre and TV
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
• UpLift™: To ease handling, clip on UpLift handles are designed to ease the burden. Handles are easily attached and removed, greatly easing carrying and lifting of larger fixtures.
• BARS™ – Brake Attribute Retention System (Patented) applied for internal movement affecting beam distribution
Control and programming
• Setting & Addressing: ROBE Navigation System 2 (RNS2)
• Display: QVGA Robe screen with battery backup, gravitation sensor for auto screen positioning, operation memory
service log with RTC, built-in analyser for easy fault finding, NFC app controller
• Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
• REAP™ – Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio – on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to
automatically maintain network connectivity
• DMX Protocol modes: 3
• Control channels: 35, 24, 39
Internal barndoors
• Patented 4Door™ internal barndoors module: Barndoors: 4 blades, each with separate movement control
• Rotation: +/- 90° module rotation
Internal Scrim
• Patented RotaScrim™ internal Scrim module: Graduated filter position control
• Rotation: +/- 180° of the entire module
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: max. 1700 W
• Power connector in: Neutrik powerCON TRUE1
• DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
• Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps
• USB connector (series A) for lightmaster purposes
