Type
Condenser, electret
Polar Pattern
Cardioid
Frequency Response
20 to 20,000 Hz
Output Impedance
70 Ω +/- 5
Sensitivity
open circuit voltage, @ 1 kHz, typical
-36 dBV/Pa[1] (16.0 mV)
Signal-to-Noise Ratio
83 dB
Maximum SPL
1 kHz at 1% THD
| No Pad | 1000 Ω load | 137 dB SPL |
| 2500 Ω load | 140 dB SPL | |
| 5000 Ω load | 140 dB SPL | |
| With 15 dB Pad | 1000 Ω load | 152 dB SPL |
| 2500 Ω load | 155 dB SPL | |
| 5000 Ω load | 155 dB SPL |
Dynamic Range
@ 1 kHz
| 1000 Ω load | 125 dB |
| 2500 Ω load | 129 dB |
| 5000 Ω load | 129 dB |
Clipping Level
20 Hz to 20 kHz, 1% THD
| 1000 Ω load | 5.6 dBV |
| 2500 Ω load | 9.5 dBV |
| 5000 Ω load | 10.2 dBV |
Self-Noise
equivalent SPL, A-weighted, typical
11 dBA
Common Mode Rejection
20 Hz to 20 kHz
>50 dB
Attenuator Switch
0, -15 dB
Low Frequency Filter Switch
Flat, -6 dB/octave below 115 Hz, or -18 dB/octave below 80 Hz
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Connector
Three-pin professional audio (XLR), male, balanced
Weight
265 g (9.17 oz.)
Housing
Machined, anodized aluminum alloy
Dimensions
47.6 x 154.2 mm (1.87 x 6.07 in.)
Power Requirements
48 V DC phantom power (5.4 mA), IEC standard 61938, P48
[1] 1 Pa=94 dB SPL
