CHAUVET Intimidator Spot 360QD

Innovative moving head designed for the mobile entertainer or permanent installation
Wide color range, increased CRI, and crystal-clear optics from the RGBL light engine
Carbon fiber composite housing material is exceptionally strong, resists corrosion, and reduces weight
Built-in D-Fi transceiver for wireless DMX or master/slave communications
Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
Dual rotating prisms split the beam for great effects and cover a larger area
Project crisp gobos from nearly any distance with the motorized focus
Beams always remain on the dance floor using the built-in, innovative Totem mode
PowerCON®-compatible power input/output connections saves setup time
Onboard USB-C port allows for quick software updates

分類: Chauvet, Chauvet

Technical Specifications
Overview
Fixture Type	Professional LED Moving Head Spot Fixture
Light Source & Performance
Light Source	1 LED (quad-color RGBL) 220W, (2.5A), 50,000 hours life expectancy
Optics & Beam Angle	Beam Angle: 17° Lumens: 4,474
Illuminance	@ 2 m: 17,242 lux @ 5 m: 2,759 lux
Strobe Rate	0 to 25 Hz
Gobos & Effects
Gobos	Gobo Wheel: 7 + open (6 metal + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds Gobo Size: 24 mm outside, 20 mm image, 0.5 mm max thickness
Prisms	5-facet linear, bi-directional at variable speeds; 6-facet round, bi-directional at variable speeds
Movement
Pan & Tilt Ranges	Pan: 540° (Ranges: 540°, 360°, 180°) Tilt: 270° (Ranges: 270°, 180°, 90°)
Control & Connectivity
DMX Channels & Connectors	Channels: 11 or 18 Connectors: 3- and 5-pin XLR Optional Controllers: RFC, RFC-XL
Electrical & Power
Input Voltage & Power	Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 324 W, 2.7 A @ 120 V, 60 Hz; 322 W, 1.3 A @ 230 V, 50 Hz
Power Linking	4 units @ 120 V; 8 units @ 230 V
Physical & Certifications
Dimensions & Weight	Size: 12.5 x 8.6 x 17.1 in (319 x 220 x 435 mm) Weight: 20.4 lb (9.2 kg)
Approvals	CE, RoHS, MET
