| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional LED Wash Fixture |
| Light Source & Performance | |
| Light Source | 6 LEDs (tri-color RGB) 4.8 W, (2 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle: 17° Field Angle: 33° |
| Illuminance | @ 2 m: 1,754 lux |
| Strobe Rate | 0 to 20 Hz |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 3 or 7 Connectors: 3-pin XLR Optional Controllers: IRC6, ILS Command |
| Wireless & Bluetooth | Bluetooth Version: 4.2 Operating Frequency: 2.4 GHz Max Unobstructed Distance: 150 ft (25.7 m) |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 21 W, 0.3 A @ 120 V, 60 Hz; 21 W, 0.3 A @ 230 V, 50 Hz Max. Output Current: 8 A (25 units @ 120 V) (38 units @ 230 V) |
| Power Linking | 25 units @ 120 V; 38 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 10.4 x 7.6 x 3 in (265 x 218 x 76 mm) Weight: 2.2 lb (1 kg) |
| Hardware & Mounting | Bracket Mounting Hole: 13 mm |
| Approvals | CE, RoHS, FCC |
