| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional LED Wash Fixture |
| Light Source & Performance | |
| Light Source | 12 LEDs (tri-color RGB) 4.9 W, (1.19 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle: 17° Field Angle: 29° Lumens: 1,415 |
| Illuminance | @ 2 m: 3,362 lux |
| Strobe Rate | 0 to 11 Hz |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 3 or 8 Connectors: 3-pin XLR Optional Controllers: IRC-6 |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 43 W, 0.6 A @ 120 V, 60 Hz; 43 W, 0.3 A @ 230 V, 50 Hz |
| Power Linking | 13 units @ 120 V; 23 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 8.8 x 8.8 x 9.7 in (224.5 x 225.5 x 246 mm) Weight: 3.6 lbs (1.6 kg) |
| Hardware & Mounting | Bracket Mounting Hole: 13 mm |
