| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional LED Wash Fixture |
| Light Source & Performance | |
| Light Source | 2 LEDs (penta-color RGBA+WW) 130 W, (2.8 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle: 62° Field Angle: 105° |
| Illuminance | @ 2 m: 1,300 lux |
| Strobe Rate | 0 to 20 Hz |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 4, 7, 12, or 20 Connectors: 3- and 5-pin XLR Optional Controllers: DMX, RDM |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 120 W, 1 A @ 120 V, 60 Hz; 118 W, 0.5 A @ 230 V, 50 Hz |
| Power Linking | 12 units @ 120 V; 22 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 16.6 x 3.8 x 9.1 in (422 x 98 x 232 mm) Weight: 8.2 lb (3.7 kg) |
| Hardware & Mounting | Bracket Mounting Hole: M13 |
| Approvals | CE, MET, RoHS |
