| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional Compact LED Moving Head Spot Fixture |
| Light Source & Performance | |
| Light Source | 1 LED (cool white) 10 W, (2.1 A), 50,000 hours life expectancy |
| Optics & Beam | Beam Angle: 13° |
| Illuminance | @ 2 m: 1,561 lux |
| Strobe Rate | 0 to 23 Hz |
| Colors, Gobos & Effects | |
| Colors | 7 + white |
| Gobos | 7 + open |
| Movement | |
| Pan & Tilt Ranges | Pan: 540° Tilt: 180° |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 6 or 12 Connectors: 3-pin XLR Optional Controllers: IRC-6 |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 41 W, 0.6 A @ 120 V, 60 Hz; 38 W, 0.4 A @ 230 V, 50 Hz |
| Physical & Certifications | |
| Dimensions & Weight | Size: 7.5 x 5 x 11 in (190 x 127 x 279 mm) Weight: 5.0 lb (2.3 kg) |
| Approvals | CE |
