CHAUVET Intimidator Spot 260X

Compact moving head designed for mobile events
Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
New home position allows for smoother programming
¼-turn hanging bracket allows for quick removal when needed
Project crisp gobos from nearly any distance with the motorized focus
Manual zoom for short or long throw applications
3-facet prism splits the beam and covers a larger area
Beams always remain on the dance floor using the built-in, innovative Totem mode
Set, save, and recall 1 scene manually, directly from the full-color LCD display
Link up to 4 fixtures to create eye-catching, synchronized shows in Automated or Sound mode
powerCON®-compatible power input/output connections saves setup time
Fits best in the CHS-2XX VIP Gear Bag
Available in black or white to fit different applications

分類: Chauvet, Chauvet

Technical Specifications
Overview
Fixture Type	Professional LED Moving Head Spot Fixture
Light Source & Performance
Light Source	1 LED (cool white) 75 W, (3.3 A), 50,000 hours life expectancy
Optics & Zoom	Zoom Angle (Manual): 12° to 17° Color Temperature: 5,900 K
Illuminance	@ 2 m: 17,458 lux (12°) / 12,848 lux (17°)
Strobe Rate	0 to 20 Hz
Colors, Gobos & Effects
Colors	8 + white, split colors, continuous scroll at variable speeds
Gobos	Gobo Wheel: 7 + open (6 aluminum + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds Gobo Size: 24 mm outside, 20 mm image, 1.1 mm max thickness
Prism	3-facet round, static
Movement
Pan & Tilt Ranges	Pan: 540° (Ranges: 540°, 360°, 180°) Tilt: 234° (Ranges: 234°, 180°, 90°)
Control & Connectivity
DMX Channels & Connectors	Channels: 8 or 14 Connectors: 3-pin XLR Optional Controllers: RFC, RFC-XL
Electrical & Power
Input Voltage & Power	Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 124 W, 1.8 A @ 120 V, 60 Hz; 128 W, 1 A @ 230 V, 50 Hz
Power Linking	7 units @ 120 V; 11 units @ 230 V
Physical & Certifications
Dimensions & Weight	Size: 9.1 x 6.4 x 13.8 in (232 x 163 x 351 mm) Weight: 12.2 lb (5.6 kg)
Hardware & Mounting	Bracket Mounting Hole: 13 mm
Approvals	CE, UKCA, RoHS
