CHAUVET Shocker FX

Versatile blinder, wash and strobe light with brilliant eye candy effects
12 controllable sections (8 RGB + 4 white) allow for creative programming flexibility
Trigger eye-catching effects with built-in automated programs via Master/Slave, DMX mode or optional IRC-6 remote
Combine zone control and special effect macros for stunning visual impact
Save time running cables and extension cords by power linking multiple units
Easily transports in the optional CHS-25 VIP gear bag

Technical Specifications
Overview
Fixture Type	Professional LED Strobe / Wash Fixture
Light Source & Performance
Light Source	280 LEDs (tri-color) 50 W, (1.5 A), 50,000 hours life expectancy 56 LEDs (cool white) 11 W, (0.8 A), 50,000 hours life expectancy
Optics & Coverage	Beam Angle: 97° Field Angle: 139° Lumens: 1,981
Illuminance	@ 2 m: 219 lux
Strobe Rate	0 to 20 Hz
Control & Connectivity
DMX Channels & Connectors	Channels: 8, 18, 30, or 43 Connectors: 3-pin XLR
Electrical & Power
Input Voltage & Power	Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 45 W, 0.6 A @ 120 V, 60 Hz; 45 W, 0.4 A @ 230 V, 50 Hz
Power Linking	12 units @ 120 V; 20 units @ 230 V
Physical & Certifications
Dimensions & Weight	Size: 10.2 x 3.25 x 5.1 in (260 x 82.6 x 129 mm) Weight: 2.0 lb (1.0 kg)
Approvals	CE, RoHS
