TECHNICAL SPECIFICATIONS
| Loudspeaker Technical Specifications | |
|---|---|
| Acoustic Performance | |
| Frequency Range (-10 dB) | 40 Hz – 20 kHz |
| Frequency Range (-3 dB) | 50 Hz – 20 kHz |
| Horizontal Coverage | 90° |
| Vertical Coverage | 50° |
| Maximum SPL Peak | 118 dB |
| Transducers | |
| Low Frequency | 10 in / 254 mm with ferrite |
| High Frequency | 6x 2.0 in / 51 mm silk dome tweeters |
| Power Amplifiers | |
| System Power Amplification | 1300 watts peak |
| Low Frequency Power Amplifier | Rated Power: 1000 watts peak Rated THD: <1% Cooling: Active Design: Class D |
| High Frequency Power Amplifier | Rated Power: 300 watts peak Rated THD: <1% Cooling: Active Design: Class D |
| System Processing | |
| Voicing | 3 speaker modes |
| Reverb | Off, 1 (short), 2 (medium), 3 (long) |
| Equalization | |
| Low | +5 / -15 dB @ 90 Hz |
| High | +5 / -15 dB @ 6.0 kHz |
| Input / Output | |
| Input Type | 2x Female XLR Balanced 4x 1/4″ Balanced / Unbalanced 1/4″ Stereo |
| Mic-Line Impedance | 8 kΩ balanced |
| 1/4″ Hi-Z Impedance | 1 MΩ unbalanced |
| Mix Out | Male XLR Balanced |
| Mix Out Impedance | 600 Ω balanced |
| Bluetooth Information | |
| Bluetooth Protocol | 4.2 |
| Bluetooth Function | Audio Streaming and User Interface Control |
| Bluetooth Class | Class 1 |
| Crossover Point | |
| Crossover Frequency | 600 Hz (18 dB Butterworth) |
| Line Input Power | |
| Detachable line cord | ~100 – 240VAC, 50 – 60 Hz, 110W |
| AC Connector | 3-Pin IEC 250VAC, 10 A male |
| Power Supply Type | Switchmode |
| Safety Features | |
| Input Protection | Peak and RMS limiting, power supply and amplifier thermal protection |
| Status Info | Input and output levels, reverb levels, sig / OL, EQ settings, speaker mode |
| Construction Features | |
| Basic Design | Asymmetrical |
| Enclosure Material | Polypropylene |
| Enclosure Finish | Black Polyurea |
| Grille Material | Perforated steel |
| Grille Finish | Powder-coated black |
| Handles | One on the top panel of the base station |
| Display LEDs | Front: Defeatable power Top: Power, Limiter, Bluetooth |
| Operating Temperature | 0 – 40 °C // 32 – 104 °F |
| Physical Properties (product) | |
| Base Station | Height: 17.0 in / 432 mm Width: 13.0 in / 330 mm Depth: 14.2 in / 361 mm |
| High Frequency Section | Height (each): 22.5 in / 572 mm Height (total): 67.5 in / 1715 mm Height (total w/base): 79.0 in / 2007 mm Width: 2.8 in / 71 mm Depth: 3.0 in / 76 mm |
| Weight (total) | 29.6 lb / 13.4 kg |
