MACKIE SRM212 V-Class High-Performance Powered Loudspeaker

  • 2000W Class-D Amplifier
    • Our most advanced amplifier platform ever, delivering incredible stability, headroom and audio fidelity
    • Highest SPL in its class
    • Unrivaled reliability and rock-solid operation can withstand the most demanding applications
    • Universal power supply (100-240 VAC) with Power Factor Correction for stable operation even with unstable AC power
  • Custom Transducers
    • Large, powerful magnets partner with robust motors, specially designed voice coils and spiders to provide the highest possible efficiency and transient accuracy
    • 12” low-frequency driver designed for powerful yet balanced low end
    • Additional cooling vents surrounding the voice coil plus directional cabinet porting ensures maximum heat dispersion and reliability
    • Premium polymer high-frequency driver provides the flattest possible response for incredibly smooth highs that sound natural and balanced
  • Custom Sym-X™ Horn
    • Allows for total efficiency from the HF transducer, minimizing distortion and increasing output
    • Creates a perfectly symmetrical, flat response at the crossover point for exceptionally smooth midrange
    • The horn-loading frequency is set below the LF capability of the driver for maximum efficiency and optimal performance at the crossover point
  • Advanced Impulse™ DSP
    • Crystal-clear sound across the entire dispersion zone means the whole room is the sweet spot
    • Precision crossover and transducer time-alignment ensures balanced and accurate sound
  • Transparent System Protection
    • Dedicated processing module monitors and protects the amplifier in real time
    • Sound quality and tonal balance is maintained even under heavy limiting—no “pumping” when you crank the speaker
    • Utilizing powerful multi-band compression, the amplifier can target specific frequency ranges to prevent the system from being overloaded rather than turn everything down at the expense of overall output
    • Input limiting keeps your source signal in check so if you’re sending audio that’s a bit too hot, the speaker will cool it down
  • Intelligent Bass Management™
    • Proprietary LF management technology maintains tonal balance and output level when operating at very high volumes
    • Keeps the bass tight, punchy and articulate—essential for DJs and electronic musicians
  • SRM Mix Control™
    • Dual independent channels that support mic, line and instrument signals with XLR/TRS combo inputs
    • Dedicated 1/8” stereo aux channel
    • Direct outputs on channels 1 and 2 plus mix output
    • High-contrast full color display for easy single-knob access to mixer and processing
    • Adjust channel levels and EQ
    • Application and venue-specific voicing modes
    • Variable crossover point
    • Alignment delay—up to 100 ms
    • Save and recall up to 10 user presets
    • Screensaver plus dimmer and contrast control
    • System lock with 4-digit passcode
    • Change front LED function: Green, white, off, signal present, multi (cycle through colors)
  • SRM Connect™ App
    • The SRM Connect™ app gives you access to all adjustments and settings including EQ, levels and presets
    • Control two speakers at once, wirelessly
    • DJs can dial in the right mix from the dance floor with their phone
  • Bluetooth® Streaming and Linking
    • Wirelessly link two SRM V-Class speakers for music streaming applications plus complete control over both speakers
    • Bluetooth® technology allows up to 100 meters of range between linked speakers
    • Stereo or dual zone linking modes allows discrete control over the inputs and outputs of the entire system across two rooms or zones
    • Creates an incredibly clean setup in minutes
分類: ,

SPECIFICATIONS

Loudspeaker Technical Specifications
Acoustic Performance
Frequency Response (-10 dB) 45 Hz – 20 kHz [SRM210] 42 Hz – 20 kHz [SRM212] 40 Hz – 20 kHz [SRM215]
Frequency Response (-3 dB) 55 Hz – 20 kHz [SRM210] 50 Hz – 20 kHz [SRM212] 44 Hz – 20 kHz [SRM215]
Horizontal Coverage 90°
Vertical Coverage 60°
Maximum SPL Peak 131 dB [SRM210] 135 dB [SRM212] 136 dB [SRM215]
Monitor Angle 45°
Transducers
Low Frequency 10 in / 254 mm [SRM210] 12 in / 305 mm [SRM212] 15 in / 381 mm [SRM215] with ferrite
High Frequency 1.4 in / 36 mm polymer compression driver
Power Amplifiers
System Power Amplification – Rated Power 2000 watts peak
Low Frequency Power Amplifier Rated Power: 1800 watts peak
Rated THD: <1%
Cooling: Convection
Design: Class D
High Frequency Power Amplifier Rated Power: 200 watts peak
Rated THD: <1%
Cooling: Convection
Design: Class D
System Processing
Voicing 10 speaker modes [5 inside, 5 outside]
Subwoofer HPF Off, DRM18S, Var
Input EQ 3-band
Delay 0 – 100 ms
Equalization
Low ±12 dB @ 80 Hz
Mid ±12 dB @ 2.5 kHz
High ±12 dB @ 5 kHz
HPF 20 Hz – 150 Hz (Var)
Input / Output
Input Type 2x Female XLR Balanced
1/4″ Balanced
1/8″ Stereo
Mic-Line Impedance 20 kΩ balanced
1/4″ Hi-Z Impedance 100 kΩ balanced
Direct Out and Mix Out Male XLR Balanced
Mix Out Impedance 300 Ω balanced
Main Control Rotating Knob
Bluetooth Information
Bluetooth Protocol 4.2
Bluetooth Function Audio Streaming and User Interface Control
Bluetooth Class Class 1
Electronic Crossover
Crossover Type 24 dB / octave
Crossover Frequency 2.0 kHz
Line Input Power
Detachable line cord ~100 – 240 VAC, 50 – 60 Hz, 110W
~220 – 240 VAC, 50 – 60 Hz, 110W
AC Connector 3-Pin IEC 250 VAC, 10 A male
Power Supply Type Switchmode
Safety Features
Input Protection Peak and RMS limiting, power supply and amplifier thermal protection, overcurrent, over-voltage, dynamic thermal protections and forced air-cooling
Display LEDs Defeatable front power, speaker control
Status Info Input and output levels, voicing mode, sub HPF, EQ and delay settings
Construction Features
Basic Design Asymmetrical
Enclosure Material Black Polypropylene
Enclosure Finish Light Black Texture
Grille Material 16-18 gauge perforated steel w/nylon net backing
Grille Finish Powder-coated black
Handles One [SRM210], two on each side and one partial on top [SRM212 and SRM215]
Display LEDs Front: Power / Signal
Rear: Speaker Control
Operating Temperature 0 – 40 °C // 32 – 104 °F
Physical Properties (product)
SRM210 | V-Class Height: 23.0 in / 584 mm
Width: 15.1 in / 384 mm
Depth: 12.9 in / 328 mm
Weight: 30.9 lb / 14.0 kg
SRM212 | V-Class Height: 25.9 in / 658 mm
Width: 15.2 in / 386 mm
Depth: 14.2 in / 361 mm
Weight: 40.6 lb / 18.4 kg
SRM215 | V-Class Height: 28.8 in / 732 mm
Width: 17.6 in / 447 mm
Depth: 15.4 in / 391 mm
Weight: 48.9 lb / 22.2 kg
