| Technical Specifications | |
|---|---|
| Electronic Specifications | |
| FTC Power Output Rating | 75 W |
| Power Output per Channel | 75 W into 4, 8 or 16 ohms |
| Number of Channels | 2 |
| Total Harmonic Distortion | 0.5% max at any power level from 250 mW to rated power (20Hz to 20kHz) (≤ 0.25% harmonic distortion at 1kHz) |
| S/N below rated output | 105 dB |
| Dynamic Headroom | 1.2 dB |
| Damping Factor | >22 |
| Rated Power Band | 20Hz to 20kHz |
| Frequency Response | +0, -0.5dB from 20Hz to 20kHz +0, -3.0dB from 10Hz to 100kHz |
| General Specifications | |
| Circuit Configuration | Unity Coupled |
| Circuit Design | Vacuum Tube |
| Mono Bridge / Mono Parallel | Yes / Yes (150W @ 2, 4 or 8 Ohms) |
| Output Type | Unity Coupled Output Transformer |
| Meters & Lighting Control | No Meters (Small signal tubes LEDs controlled by McIntosh preamp) |
| Connectivity & Control | |
| Balanced Input | Yes |
| Speaker Binding Post Type | Patented Solid Cinch™ Speaker Binding Posts |
| Remote Power Control | Yes (Input and Output) |
| Multi-Channel DB25 Cable | N/A |
| Physical Features & Construction | |
| Front Panel | N/A |
| Illumination | Small Signal Tubes, LED |
| Chassis Style | Polished Stainless Steel |
| Weights & Dimensions | |
| Unit Dimensions (W x H x D) | 16-1/2″ (41.9cm) x 8-1/2″ (21.6cm) x 12″ (30.5cm) |
| Unit Weight | 67 lbs (30.5 kg) |
| Shipping Weight | 75 lbs (34.1 kg) |
