SPECIFICATION
SOURCE
• Light source: 60W RGBW LED
• LED life expectancy: min. 20.000 hrs
• Typical lumen maintenance: 70% @ 20.000 hrs
OPTICAL SYSTEM
• Robe’s proprietary optical design
• High – efficiency zoom optical system, ratio 7:1
• Zoom range: 4° – 28°
• Output lens diameter: 110 mm
• Light output: 9.270 lx @ 5m
• Fixture total lumen output: 920 lm
DYNAMIC EFFECTS
• Colour mixing mode RGBW or CMY
• Variable CTO: 2.700K – 8.000K
• Virtual Colour Wheel: with 66 preset swatches
• Tungsten lamp effect at whites: 2.700 K and 3.200 K (red shift
and thermal delay)
• Colour rainbow effect with variable speed
• MCFE™ – Multi-Coloured Flower Effects – creating spectacular
multicolour beam effects in the air rotating in both directions at
variable speed (patent pending)
• Prism: 3-facet circular rotating prism
• Motorized zoom
• Shutter: Electronic with variable speed strobe (max.20 flashes per
second)
• Pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
CONTROL AND PROGRAMMING
• Setting & Addressing: two-row LCD display & 4 control buttons,
stand-alone operation with 3 editable programs (each up to 40
steps)
• Protocols: USITT DMX-512, RDM
• Wireless CRMX™ technology from Lumen Radio: On request
• DMX Protocol modes: 2
• Control channels: 27, 21
• Pan/Tilt resolution: 16 bit
• RGBW or CMY: 8 or 16 bit
• Zoom: 8 or 16 bit
• Dimmer: 8 or 16 bit (internal 18 bit)
