Specifications
| RACK RECEIVER SPECIFICATIONS | |
| Input Voltage & Current |
• Input Voltage: 11 – 13 V ⎓ or PoE IEEE 802.3af Class 0 (shielded CAT5e or higher, S/FTP or S/STP) • Input Current: ≤ 1 A at 12 V DC |
| Power Consumption | Max. 12 W |
| Wireless & Audio Power |
• Transmit Power (BLE): max. 10 mW EIRP • Audio Output Power: 18 dBu max. • Headphone Output: 2x 70 mW @ 32 Ω |
| Network & Dante Interface |
• Network Control: RJ-45 socket, IEEE802.3 (shielded CAT5e or higher, S/FTP or S/STP) / 1000Base-T (full duplex), 100Base-TX (half+full duplex), 10Base-T (half+full duplex) • Digital Audio Output: Dante®, RJ-45 (48 kHz, 96 kHz, 24 bit) |
| Dimensions & Weight |
• Dimensions: 212 x 44 x 169 mm (8.35″ x 1.73″ x 6.65″) • Weight: approx. 1000 g (2.2 lbs) without antennas and power supply |
| GLOBAL SYSTEM SPECIFICATIONS | |
| Audio Link Frequency Ranges |
• Q1-9: 470.2 – 550 MHz • R1-9: 520 – 607.8 MHz • S1-10: 606.2 – 693.8 MHz • S2-10: 614.2 – 693.8 MHz • S4-10: 630 – 693.8 MHz • U1/5: 823.2 – 831.8 MHz & 863.2 – 864.8 MHz • V3-4: 925.2 – 937.3 MHz • V5-7: 941.7 – 951.8 MHz & 953.05 – 956.05 MHz & 956.65 – 959.65 MHz • Y1-3: 1785.2 – 1799.8 MHz |
| Bluetooth Frequency Range | 2402 – 2480 MHz (Bluetooth® Low Energy) |
| Audio Performance |
• Audio Frequency Response: 20 Hz – 20 kHz (-3 dB) • Audio THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level • Dynamic Range: 134 dB |
| System Latency | 1.9 ms |
| Environmental Conditions |
• Operating Temperature: -10 °C – +50 °C (14 °F – 122 °F) • Relative Humidity: 5 – 95 % (non-condensing) |
