Specifications
| GENERAL DIGITAL | |
| Sample Rate | 48 kHz |
| A/D/A Bit Depth | 24-bit |
| System Latency | ~3 ms |
| Equivalent Noise | -143.4 dBV (A-weighted) |
| PRODUCT FEATURES | |
| On/off switch | No |
| PRODUCT | |
| Transducer type | Condenser / Dynamic |
| Color | Black |
| Total harmonic distortion (THD) | < 0.9 % |
| Certifications | CE, FCC, IC |
| FREQUENCY SPECIFICATIONS | |
| Frequency range | GW (558 – 626 MHz) |
| Audio frequency response | 40 – 16,000 Hz / 40 – 18,000 Hz / 40 – 20,000 Hz / 80 – 18,000 Hz |
| ACOUSTIC PROPERTIES | |
| Pickup pattern | Cardioid / Supercardioid |
| Signal-to-noise ratio | ≥ 120 dBA (@ 1 mV peak deviation) |
| INPUTS | |
| Inputs | 2x balanced/unbalanced combo jacks, 4x balanced/unbalanced combo jacks, 1/4″ balanced/unbalanced stereo jacks, 1/8″ stereo jack |
| XLR Mic Pre | Onyx 80 mic preamps |
| Input Impedances |
• 4 kΩ balanced (microphone) • 10 kΩ balanced (instrument) • 5 kΩ unbalanced (instrument) |
| OUTPUTS | |
| Outputs | Balanced/unbalanced 1/4″ main out jacks, 2x stereo headphone jacks, 4x stereo headphone jacks |
| Line Output Maximum Level | 14 dBu |
| Headphone Output Power | 30 mW |
| BLUETOOTH • USB • SD | |
| Bluetooth | 5.0 |
| USB | Format: USB 2.0 HS (480Mb/s) |
| SD |
• Multitrack (12 chan + main mix) / 24-bit / 48kHz • SD speed class 10 or speed class UHS recommended |
| RECORDING / NETWORKING | |
| Recording Storage | microSDHC, microSDXC, USB-A removable drive (FAT32 – minimum 100MB/s) |
| Data Transfer | Integrated SD 3.0 104 MB/s |
| Network Connectivity | Ethernet 10/100 |
| CONNECTIVITY | |
| Connection | Wireless |
| BATTERY & POWER | |
| Battery included | Y / N |
| Battery capacity (Ah) | 2.3 |
| Battery count | 2 |
| Battery voltage (V) | 1.5 |
| Battery specification | 2 x 1.5 V (AA) |
| Battery operating time (h) | > 8 h (P48: 5h) |
| Line Input Power | 18V ⎓ 1.5A |
| ELECTRICAL PROPERTIES | |
| Sensitivity | 1.6 mV/Pa / 1.8 mV/Pa / 2.1 mV/Pa |
| Sensitivity in free field, no load (1kHz) | 1.6 mV/Pa / 1.8 mV/Pa / 2.1 mV/Pa |
| DIMENSIONS (PRODUCTS) | |
| Base Wireless Unit Dimensions | 105 x 43 x 43 mm |
| Product weight (g / lb / kg) | 92 g / 112 g / 119 g / 329 g / 380 g / 1.2 kg (2.6 lb) / 2.8 kg (6.1 lb) |
| Product height | 80 mm / 83 mm (3.3 in) / 103 mm (4.1 in) / 350 mm |
| Product length / depth | 72.3 mm / 77.3 mm / 135 mm / 140 mm / 204 mm (8.0 in) / 381 mm (15.0 in) |
| Product width | 66 mm / 115 mm / 260 mm (10.2 in) / 330 mm (13.0 in) |
| Product diameter (mm) | 50.5 |
| PHYSICAL PROPERTIES (PACKAGED PRODUCT) | |
| Height | 94 mm (3.7 in) / 216 mm (8.5 in) |
| Width | 307 mm (12.1 in) / 386 mm (15.2 in) |
| Depth | 226 mm (8.9 in) / 399 mm (15.7 in) |
| Weight | 1.7 kg (3.7 lb) / 4.9 kg (10.9 lb) |
