Specifications
| Light Source | |
| Light source | 1 × 350W LED |
| Fixture luminous flux | 13,000 lumens |
| Fixture color temperature | 5600±200K |
| Light source expected lifespan | 20,000 hours * Data provided by light source supplier |
| Optical System | |
| Lens angle | 5°/10°/14°/19°/26°/36°/50° |
| Lens selection | 15°-30° manual smooth focusing 25°-50° manual smooth focusing |
| Control & Program | |
| Mechanical buttons | 4 mechanical buttons |
| Control panel | LCD display |
| Control protocol | DMX512, RDM |
| DMX channel mode | 1 type |
| Control channels | 4 |
| Software upgrade | Upgrade software via DMX connection |
| AIoT system | AIoT Fengyun system, “Yi·Data” automatic management system (optional) |
| Other Effects | |
| Strobe, dimming and other functions | Available |
| Noise level | Low noise, noise below 34.8dB within 1 meter range |
| Heat dissipation design | Excellent heat dissipation design, long LED lifespan |
| Dimming | 0-100% smooth dimming |
| Electrical & Interface | |
| Input voltage range | 180-240Vac; 50/60Hz |
| Power | 400W |
| Power socket | Power connector input/output |
| Signal input/output | 3-pin XLR socket |
| Fixture Specifications | |
| Fixture dimensions | Width: 615 mm , Height 304mm, Depth 300mm |
