ACME THEATRE SPOT 500 WW

THEATRE SPOT 500 WW, a new high-CRI spot light with light weight and low noise, boasts a powerful 450-Watt WW LED engine calibrated at 3,200K that delivers a 28,000 lumens output with a 250 mm frontal lens.

The fixture features a high-effciency optical system delivering a 5.5:1 zoom ratio with a zoom range of 14° to 74°. With a built-in fan, the heat dissipation in silent operation is significantly improved. Its patented hanger design prevents changes in the illumination angle from unexpected movements.

Equipped with flicker-free operation, a rotatable barndoor, and low noise design ,the THEATRE SPOT 500 WW is suitable for various applications such as exhibitions, theaters, broadcasts, and film shooting, ensuring perfect illumination.

分類: Acme Lighting, Acme Lighting

描述

Technical Specifications
Light Source & Photometric Data
Light Source	450W Warm White (WW) LED engine (20,000 hours rated life)
Total Lumen Output	28,000 lm
Color Temperature & CRI	3,200K \| HCRI Mode: Ra > 97 (Color correction system ensures consistent output)
Optical System
Zoom Range & Lens	Zoom Range: 14° – 74° (5.3 : 1 ratio, Motorized) Frontal Lens Diameter: 250 mm
Performance Features
Strobe & Dimming	Variable speed strobe, smooth 0–100% dimming (4 user-selectable dimming curves)
Acoustics & Broadcast	Low noise operation (< 33.9 dB @ 1m), flicker-free management under 4K/8K cameras
Included Accessories	Rotatable barndoor included
Control & Electrical
Control Protocols & Channels	DMX512, RDM, Art-Net, sACN (2 DMX modes: 4 / 6 Channels) \| DMX & Manual Control
Display & Firmware	4-touch button control panel with LCD display; firmware upgrade via DMX link
Input Voltage & Power	100–240 Vac, 50/60 Hz \| Power Consumption: 460 W
Connectors	Power: Power connector in/out Data: 3-pin or 5-pin XLR, RJ45 connector
Physical, Packaging & Environment
Fixture Dimensions & Weight	320 x 569 x 462 mm (12.6″ x 22.4″ x 18.2″) \| Weight: 13.2 kg (29.2 lbs)
Packaging Options	Carton (One-pack): 720 x 420 x 540 mm (28.3″ x 16.5″ x 21.3″) \| G.W.: 18.5 kg (40.8 lbs)
Operating Environment	Ambient Temp: 0°C to 40°C \| Max Surface Temp: 55°C Protection Rating: IP20
Installation & Included Items	Horizontal or vertical mounting, universal working position (1x omega bracket [3002000238], safety cable attachment point, rotatable barndoor, power cable, digital manual)
