| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional Multi-Effect Lighting System (Pars, Strobe & Derby) |
| Package Includes | GigBAR Flex, Power cord, Carrying bag, Wireless footswitch, IRC-6 |
| Light Source & Performance | |
| Light Source | Pars: 6 LEDs (quad-color RGB+UV), 3.5 W (1 A), 50,000 hours life expectancy Strobe: 4 LEDs (white & UV), 5 W (1.5 A), 50,000 hours life expectancy Derby: 6 LEDs (2 red, 2 green, 2 blue), 5 W (1.6 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle (Pars): 13° Field Angle (Pars): 24° Beam Angle (Strobe): 8° Field Angle (Strobe): 18° Coverage Angle (Derby): 114° |
| Illuminance | Pars @ 2 m: 1,078 lux (per head) Strobe @ 2 m: 86 lux (per zone) |
| Strobe Rate | 0 to 18 Hz |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 3, 8, or 20 Connectors: 3-pin XLR |
| Wireless Footswitch | Operating Frequency: 433 MHz Max Unobstructed Distance: 100 ft (30.5 m) Battery: 12 V A 23 |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 45 W, 0.7 A @ 120 V, 60 Hz; 46 W, 0.4 A @ 230 V, 50 Hz |
| Power Linking | 12 units @ 120 V; 22 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 37 x 4 x 15 in (949 x 110 x 388 mm) Weight: 11 lbs (5 kg) |
| Approvals | CE |
