| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional LED Wash Fixture |
| Light Source & Performance | |
| Light Source | 18 LEDs (hex-color RGBAW+UV) 6.2 W, (1.6 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle: 27° Field Angle: 43° Lumens: 3,356 |
| Illuminance | @ 2 m: 3,111 lux |
| Strobe Rate | 0 to 20 Hz |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 6, 8, 12, or 22 Connectors: 3-pin XLR Optional Controllers: IRC-6, ILS Command |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 68 W, 1 A @ 120 V, 60 Hz; 67 W, 0.5 A @ 230 V, 50 Hz |
| Power Linking | 8 units @ 120 V; 14 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 8.2 x 14 x 2.2 in (208 x 355 x 55 mm) Weight: 6 lb (2.7 kg) |
| Hardware & Mounting | Bracket Mounting Hole: 13 mm |
| Approvals | CE, RoHS |
