SPECIFICATIONS
| Loudspeaker Technical Specifications | |
|---|---|
| Acoustic Performance | |
| Frequency Response (-10 dB) | 52 Hz – 23 kHz |
| Frequency Response (-3 dB) | 59 Hz – 23 kHz |
| Horizontal Coverage | 90° |
| Vertical Coverage | 60° |
| Maximum SPL Peak | 127 dB |
| Monitor Angle | 40° |
| Transducers | |
| Low Frequency | 10 in / 254 mm woofer with ferrite |
| High Frequency | 1.0 in / 25 mm polymer compression driver |
| Power Amplifiers | |
| System Power Amplification – Rated Power | 1400 watts peak |
| Low Frequency Power Amplifier |
Rated Power: 1200 watts peak Rated THD: <1% Cooling: Convection Design: Class D |
| High Frequency Power Amplifier |
Rated Power: 200 watts peak Rated THD: <1% Cooling: Convection Design: Class D |
| Input / Output | |
| Input Type | 2x Female XLR – 1/4″ Balanced TRS combo jack and 1/8″ TRS |
| Mic/Line Impedance | 10 kΩ Balanced |
| 1/8″ Line Impedance | 10 kΩ Balanced |
| Thru Out | Male XLR Balanced |
| Thru Out Impedance | 300 Ω Balanced |
| Electronic Crossover | |
| Crossover Frequency | 2.1 kHz |
| Bluetooth Information | |
| Bluetooth Protocol | 5.0 |
| Bluetooth Function | Audio streaming and user interface control |
| Line Input Power | |
| Detachable line cord | 100–240V~, 50–60 Hz, 75W |
| AC Connector | 3-pin IEC 250 VAC, 10 A male |
| Power Supply Type | Switchmode |
| System Processing | |
| Voicing | Four speaker modes |
| Safety Features | |
| Input Protection | Peak and RMS limiting, power supply and amplifier thermal protection |
| Feedback Eliminator | On / Off |
| Display LEDs | Voicing Mode, Outdoor Mode, Music Ducking, Feedback Eliminator, Front LED, Bluetooth Status, Link Status, Overload |
| Mounting Methods | |
| Supported Methods |
Floor mount, pole mount via the built-in socket on the bottom of the cabinet [Be sure the pole is capable of supporting the weight of the ThumpXT loudspeaker] or fly via the integrated M10 mounting points (using M10 x 1.5 x 20 mm forged shoulder eyebolts). See the owner’s manual for more information. |
| Options | |
| Thump210XT Speaker Bag | P/N 2057761 |
| T100 Loudspeaker Tripod Stand | P/N 2052464 |
| SPM400 M20 Threaded Loudspeaker Pole Mount | P/N 2051055 |
| PA-A3 Forged Shoulder Eyebolt Kit (3 x M10 x 17 mm) | P/N 2036960 |
| Physical Properties (Product) | |
| Height | 22.4 in // 569 mm |
| Width | 13.0 in // 330 mm |
| Depth | 12.8 in // 325 mm |
| Weight | 25.6 lb // 11.6 kg |
