Specifications
| Charging capacity | Up to 8 battery packs (BA 60, BA 61, BA 62, BA 70) via 4 exchangeable charging modules (LM 6060, LM 6061, LM 6062, LM 6070) |
| Charging time BA 60 (at 20 °C) | 80 %: approx. 1:15 h 100 %: approx. 2:30 h |
| Charging time BA 61 (at 20 °C) | 80 %: approx. 1:45 h 100 %: approx. 3:15 h |
| Charging time BA 62 (at 20 °C) | 80 %: approx. 1:15 h 100 %: approx. 2:45 h |
| Charging time BA 70 (at 20 °C) | 80 %: approx. 1:45 h 100 %: approx. 3:30 h |
| Charging temperature range | 0 to 50 °C |
| Charging status display | Multi-colored |
| Network | IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection |
| Power supply | 100 to 240 V AC, 50/60 Hz |
| Maximum power consumption | 85 W |
| Minimum power consumption | 1 W |
| Power plug | 3-pin, protection class I as per IEC/EN 60320-1 |
| Dimensions (H × W × D) with mounting elements | 44 × 483 × 373 mm |
| Weight | 5.1 kg |
| Ambient temperature | −10 to 55 °C |
| Relative humidity | Max. 90 % at 40 °C |
| Dripping and splashing liquids | The product must not be exposed to dripping and splashing (IP2X) |
