Product
Transducer type Dynamic
Latency (ms) 1.9 ms
Total harmonic distortion (THD) ≤ -60 dB for 1 kHz @ -3 dBfs input level
Frequency Specifications
Frequency range 606.200 – 662.000
Audio frequency response 20 Hz – 20 kHz (-3 dB) @ 3 dBfs
Acoustic Properties
Dynamic range (>) 134 dB
Audio output level 18 dBu max
Pickup pattern Cardioid
Connectivity
Connection Wireless
Ambient Conditions
Operating relative humidity (≤ %) 5 – 95 % (non-condensing)
Operating temperature (C) -10 °C – +55 °C (14 °F – 131 °F)
Battery & Power
Battery capacity (Ah) 2.3
Battery count 2
Battery included Y
Battery voltage (V) 1.5
Charging current (mA) ≤ 300 mA
Electrical Properties
Sensitivity 2.1 mV/Pa
Input voltage 11 – 13 V ⎓
Transmission power (mA) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP) BLE:
max. 10 mW EIRP
Dimensions
Dimensions 212 x 44 x 189 mm
Product weight (g) 3000
Product height 73
Product length 405
Product width 350
Bluetooth
Bluetooth transmission frequency 2402 – 2480 MHz
