Specifications
| XSW-D MINI JACK TX / RX WIRELESS SYSTEM SPECIFICATIONS | |
| RF Characteristics | • Frequency Range: 2,400 – 2,483.5 MHz • Transmission Power (EIRP): max. 10 mW • Modulation: GFSK with TDMA |
| Audio (AF) Characteristics | • Codec: aptX® Live • Audio Frequency Response (3.5 mm Jack/XLR): 80 – 18,000 Hz • Audio Frequency Response (6.3 mm Jack): 10 – 18,000 Hz • Audio Output: max. 12 dBu • Signal-to-Noise Ratio: ≥ 106 dB • THD: < 0.1 % • Audio Latency: < 4 ms |
| USB-C Charging Interface | • Input Voltage: typ. 5.0 V • Charging Temperature: 0 °C – 60 °C (32 °F – 140 °F) • Charging Time: typ. 3 hours |
| Battery Pack | • Cell Type: Li-Ion • Nominal Voltage: 3.7 V • Cell Capacity: 850 mAh • Operating Time: up to 5 hours |
| Physical Properties (TX / RX) | • Dimensions (TX & RX): approx. 86 x 24 x 28 mm • Weight (TX & RX): approx. 73 g per unit |
| Environmental Conditions | • Operating Temperature: -10 °C to +55 °C (14 °F to 131 °F) • Relative Humidity: 95 % (non-condensing) |
| ME 2-II LAVALIER MICROPHONE SPECIFICATIONS | |
| Acoustic Properties | • Transducer Principle: pre-polarized condenser • Frequency Response: 50 to 18,000 Hz • Pick-up Pattern: super cardioid • Sensitivity at 1 kHz (free field): 20 mV/Pa • Max. Sound Pressure Level (at 1 kHz): 130 dB SPL |
| Electrical & Physical | • Equivalent Noise Level (A-weighted, DIN IEC 651): 36 dB • Connector: 3.5 mm jack • Cable Length: approx. 1.60 m • Supply Voltage: 7.5 V |
| SMARTPHONE CLAMP SPECIFICATIONS | |
| Physical Properties | • Weight: 0.24 lbs / 109 g • Panoramic Rotation: 360° • Clip Size: 2.2 in / 56 mm (Min.) to 3.5 in / 89 mm (Max.) • Material: aluminum, stainless steel |
| Mounting Interfaces | • Top: Cold Shoe • Back: 4 x 1/4″ • Bottom: 1 x 1/4″, 1 x 3/8″, Arca Swiss |
| Compatibility | • Smartphones: All smartphones with maximum width of 3.5 in / 89 mm • Accessories: All products with cold shoe adapter |
| MANFROTTO PIXI MINI TRIPOD SPECIFICATIONS | |
| Product Properties | • Weight: 0.42 lbs / 190 g • Closed Length: 7.20 in / 183 mm • Height Range (Min / Max): 5.31 in / 135 mm • Tilt: Front -35° / +35°, Lateral -35° / +35° • Leg Angles: 45° • Material: aluminum, technopolymer |
| Ball Head & Loading | • Plate Type: fixed – with 1/4″ screw • Panoramic Rotation: 360° • Ball Locking: Yes • Mounting Interface (Top): 1/4″ • Safety Payload Weight: 2.2 lbs / 1 kg • Max. Body Weight: 1.4 lbs / 650 g • Max. Focal Length: 3.4 in / 85 mm |
| Environmental Conditions | • Max. Working Temperature: 140 °F / 60 °C • Min. Working Temperature: -22 °F / -30 °C |
