Specifications
| GLOBAL SYSTEM SPECIFICATIONS | |
| Transmission Frequency | 2400 – 2483.5 MHz (2.4 GHz ISM Band) |
| Codec & Modulation | aptX Live |
| Audio Frequency Response | 10 – 18,000 Hz |
| Dynamic Range & Distortion | • Dynamic Range: 106 dB • THD: < 0.1% |
| System Latency | < 3.9 ms |
| RF Output Power | max. 10 mW (EIRP) |
| Environmental Conditions | • Operating Temperature: -10 °C to +55 °C (14 °F to 131 °F) • Relative Humidity: 95% (non-condensing) |
| XSW-D PEDALBOARD RECEIVER SPECIFICATIONS | |
| Audio Outputs | • 1/4″ (6.3 mm) Jack Socket (balanced / unbalanced): -24 dBu to +12 dBu • XLR Socket (balanced): -30 dBu to 0 dBu |
| Power Supply | • Input Voltage: 9 – 15 V⎓ • Input Current: ≥ 350 mA |
| Features | Built-in guitar tuner (adjustable 440 Hz standard), Mute function |
| Dimensions & Weight | • Dimensions: Approx. 130 x 82 x 51 mm • Weight: Approx. 290 g |
| XSW-D INSTRUMENT TRANSMITTER SPECIFICATIONS | |
| Audio Input | 1/4″ (6.3 mm) Jack Socket |
| Power & Battery | • Battery Type: Built-in Li-Ion rechargeable battery • Nominal Voltage: 3.7 V • Battery Capacity: 850 mAh • Operating Time: Up to 5 hours • Charging Port: USB-C (Charging Voltage: typ. 5.0 V, Charging Time: typ. 3 hours) |
| Dimensions & Weight | • Dimensions: Approx. 122 x 24 x 28 mm • Weight: Approx. 60 g |
