| Technical Specifications | |
|---|---|
| Light Source & Color | |
| Light Source | 1,800W LED engine Rated Life: 20,000 hours (manufacturer spec) |
| Color Temp Output | 6,000K |
| Color Wheels | Color Wheel: 6 colors + open Color Temperature Wheel: 6 color temperature plates Minus Green Wheel: 3 minus-green plates |
| Photometric Data & Optics | |
| Total Lumen Output | 38,000 lm |
| Color Rendering / Indices | Ra ≥ 95, R9 ≥ 90, R15 ≥ 95, TLCI ≥ 95, CCI: 0–1.2G |
| Zoom Range & Lens | Zoom Range: 5°–15° Front Lens Diameter: 280 mm |
| Effects, Frost & Control Features | |
| Frost | 1 frost filter |
| Effects & Adjustments | Smooth 0–100% dimming (4 user curves), motorized linear iris Manual adjustment: dimmer, frost, focus, zoom, and iris Power mode: 3 power modes |
| Control & Electrical | |
| Control Protocols & Channels | Protocols: RDM | Operational Modes: DMX Control, Manual Control 1 DMX Protocol Mode / Channels: 7 |
| Display & Firmware | 26-touch button control panel with LCD display; firmware upgrade via DMX link |
| Input Voltage & Power | 180–240 Vac, 50/60 Hz Power Consumption: 2,180 W |
| Connectors | Power: Power Cord in Data: 3-pin or 5-pin XLR |
| Physical, Packaging & Environment | |
| Fixture Dimensions & Weight | Standard: 493 x 1,052 x 369 mm (19.4″ x 41.4″ x 14.5″) | Weight: 51 kg (112.4 lbs) With Tripod Stand: 787 x 1,052 x 1,425 mm (31″ x 41.4″ x 56.1″) | Weight: 74.5 kg (164.2 lbs) |
| Packaging Options | Flight Case (Standard One-pack): 1,195 x 625 x 775 mm (47.0″ x 24.6″ x 30.5″) | G.W.: 134.5 kg (296.5 lbs) |
| Operating Environment | Ambient Temp: 0°C to 40°C | Max Surface Temp: 75°C Protection Rating: IP20 |
| Approvals | CE compliant, UKCA compliant |
| Installation & Rigging | Horizontal or vertical mounting, universal working position, tripod at the bottom, safety cable point |
| Included Items | Digital user manual, power cable |
