| Technical Specifications | |
|---|---|
| Light Source & Photometric Data | |
| Light Source | 1 x 36W Warm White (WW) LED (20,000 hours rated life) |
| Color Temperature | 3,200K ± 150K |
| Color Rendering Performance | CRI ≥ 95 | CQS ≥ 95 | TLCI ≥ 95 |
| Optical System | |
| Beam Angle Options | 19°, 26°, 36°, 50° |
| Performance Features | |
| Flicker Management | Flicker-free operation for broadcast and camera applications |
| Control & Electrical | |
| Control Protocols & Channels | DMX512, RDM (2 DMX modes: 1 / 2 Channels) |
| Display & Firmware | 4-touch button control panel with LCD display; firmware upgrade via DMX link |
| Input Voltage & Power | 100–240 Vac, 50/60 Hz (electronic auto-ranging) | Power Consumption: 32 W |
| Connectors | Power: Power wire Data: 3-pin or 5-pin XLR |
| Physical, Packaging & Environment | |
| Fixture Dimensions & Weight | 158 x 273 x 100 mm (6.2″ x 10.7″ x 3.9″) | Weight: 2.0 kg (4.4 lbs) |
| Operating Environment | Ambient Temp: 0°C to 40°C | Max Surface Temp: 65°C Protection Rating: IP20 |
| Approvals | CE compliant |
| Installation & Included Items | Horizontal or vertical mounting, universal working position (feet support with 1 locking point, safety cable point, gel frame, gobo slot, metal gobo, safety cable, digital manual) |
