| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional Battery-Operated Wireless LED Compact Uplight / Accent Fixture |
| Light Source & Performance | |
| Light Source | 1 LED (hex-color, RGBWA+UV), 10 W, (3 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle: 23° Field Angle: 44° Lumens: 137 |
| Illuminance | @ 2 m: 168 lux |
| Strobe Rate | 0 to 20 Hz |
| Control & Connectivity | |
| DMX Channels & Optional Controllers | Channels: 6, 8, or 12 Optional Controllers: RFC, RFC-XL, FREEDOM Connect |
| Wireless & Range | Operating Frequency: 2.412 to 2.484 GHz Max Unobstructed Distance: 600 ft (183 m) |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 5 VDC, 1.5 A (external power supply) Power and Current: 13 W, 0.3 A @ 120 V, 60 Hz; 13 W, 0.2 A @ 230 V, 50 Hz |
| Battery & Runtime | Recharge Time: 6 hours Maximum Run Time: up to 8 hours (all on) / up to 20 hours (single color) |
| Physical & Certifications | |
| Dimensions & Weight | Size: 3 x 3 x 4.2 in (75 x 75 x 107 mm) Weight: 1.6 lbs (0.7 kg) |
| Hardware, Mounting & Environment | IP Rating: IP54 Bracket Mounting Hole: M12 Startup Temperature: -4 °F to 113 °F (-20 °C to 45 °C) Operating Temperature: -22 °F to 113 °F (-30 °C to 45 °C) |
| Approvals | CE, RoHS, FCC |
