Specifications
| Frequency range | 470 to 714 MHz |
| Transmission scheme | Digital modulation |
| Long Range Mode (LR) | Min. frequency spacing for equidistant grid: 400 kHz |
| Link Density Mode (LD) | Min. frequency spacing for equidistant grid: 200 kHz |
| Audio codec | LR Mode: SeDAC (Sennheiser Digital Audio Codec) LD Mode: SePAC (Sennheiser Performance Audio Codec) |
| Dynamic range | 111 dB (A) typ. |
| Encryption | AES 256 |
| Latency | Analog audio out: 3 ms (LR) / 3.2 ms (LD) Digital audio out (AES/EBU): 3 ms (LR) / 3.2 ms (LD) |
| Total harmonic distortion (THD) | < 0.03 % (at 1 kHz) |
| Temperature | Operation: −10 °C to +50 °C Storage: −25 °C to +70 °C |
| Relative air humidity | Operation: max. 85 % at 40 °C (non-condensing) Storage: max. 90 % at 40 °C (non-condensing) |
| Dripping and splashing liquids | The product must not be exposed to dripping and splashing (IP2X) |
| Receiving channels | 2 |
| Receiver principle | Double superheterodyne |
| Diversity | True Bit Diversity |
| Sensitivity | −100 dBm typical |
| Image rejection | > 100 dB typical |
| Blocking | > 80 dB typical |
| Audio frequency response | LR Mode: 30 Hz to 20 kHz (1.5 dB) LD Mode: 30 Hz to 14 kHz (1.5 dB) |
| Analog audio outputs | XLR-3 and 6.3 mm jack per channel (transformer balanced), −10 dBu to +18 dBu in steps of 1 dB (2 kΩ) |
| Digital audio outputs | AES3-2003, XLR-3: 48 kHz, 96 kHz, 24 bit Dante™, RJ-45 (only EM 6000 DANTE): 48 kHz, 96 kHz, 24 bit Can be externally synchronized using WCLK loop-through with BNC sockets |
| Headphone output | 6.3 mm jack, 2 × 100 mW at 32 Ω |
| Antenna inputs | 2 × BNC (50 Ω) |
| Daisy chain outputs | 2 × BNC (50 Ω) 0 dB +/− 0.5 dB amplification relative to antenna inputs |
| Daisy-chained receivers (RF) | Max. 8 EM 6000 units |
| Booster supply voltage | 12 V DC, max. 200 mA each via antenna sockets, short circuit proof |
| Word clock input | BNC, 75 Ω |
| Word clock output | BNC, 75 Ω |
| Word clock sampling rates | 48 kHz, 96 kHz |
| Network | IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection |
| Dante™ (only EM 6000 DANTE) | IEEE 802.3 (1000 Mbit/s), 2 × shielded RJ-45 connection |
| Power supply | 100 to 240 V AC, 50/60 Hz |
| Power consumption | Max. 35 W |
| Power plug | 3-pin, protection class I as per IEC/EN 60320-1 |
| Dimensions (H × W × D with mounting elements) | 44 × 483 × 373 mm |
| Weight | Approx. 5.2 kg |
