| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional LED Ellipsoidal / Spotlight Fixture |
| Light Source & Performance | |
| Light Source | 1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy |
| Optics & Zoom | Zoom Angle (Manual): 17° to 50° Beam Angle: Narrow: 17° / Wide: 50° Color Temperature: 3,500 K | CRI: 92 |
| Illuminance | @ 2 m: 4,780 lux (17°) / 998 lux (50°) @ 5 m: 853 lux (17°) / 156 lux (50°) |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 1 or 3 Connectors: 3-pin XLR Optional Controllers: D-Fi USB |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 60 W, 0.5 A @ 120 V, 60 Hz; 58 W, 0.3 A @ 230 V, 50 Hz |
| Power Linking | 16 units @ 120 V; 26 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 11.1 x 8.3 x 13 in (281 x 212 x 328 mm) Weight: 8.41 lb (3.9 kg) |
| Hardware & Accessories | Accessory Holder / Gel Frame Size: 6.25 in (158 mm) Bracket Mounting Hole: M12 |
| Approvals | CE, MET |
