| Technical Specifications | |
|---|---|
| Overview | |
| Fixture Type | Professional Multi-Effect ILS Lighting System (Moving Heads & Wash) |
| Package Includes | GigBAR Bridge ILS, Power cable, PowerCON to bare end (EU only), 2 Hanging brackets, RF Remote |
| Light Source & Performance | |
| Light Source | Moving Head: 1 LED (cool white), 40 W (3 A), 50,000 hours life expectancy Wash: 4 LEDs (hex-color RGBAW+UV), 10 W (1.3 A), 50,000 hours life expectancy |
| Optics & Coverage | Beam Angle (Wash): 22° Field Angle (Wash): 38° |
| Illuminance | Moving Head @ 2 m: 6,594 lux (per head) Wash @ 2 m: 375 lux (per section) |
| Strobe Rate | 0 to 20 Hz |
| Colors & Gobos | Colors (Moving Head): 9 + open, split colors, continuous scroll at variable speeds Gobos (Moving Head): 9 + open, continuous scroll at variable speeds |
| Control & Connectivity | |
| DMX Channels & Connectors | Channels: 3, 16, or 46 Connectors: 3-pin XLR Optional Controllers: RF, Footswitch, ILS Command |
| Wireless & Range | Operating Frequency: 2.4 GHz D-Fi Max Unobstructed Distance: 600 ft (183 m) |
| Electrical & Power | |
| Input Voltage & Power | Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging) Power and Current: 191 W, 1.5 A @ 120 VAC, 60 Hz; 175 W, 1 A @ 230 VAC, 50 Hz |
| Power Linking | 8 units @ 120 V; 13 units @ 230 V |
| Physical & Certifications | |
| Dimensions & Weight | Size: 26 x 2.8 x 12 in (660 x 71 x 305 mm) Weight: 18.6 lbs (8.4 kg) |
| Hardware & Mounting | Tripod Size Compatibility: 1.5 in (37.4 mm) |
| Approvals | CE, RoHS, FCC |
